25,000.00 - 55,000.00 / Piece
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Finishing | Polished |
| Color | Silver |
| Speciality | High Efficiency |
| Click to view more | |
Product Details
Voltage
110-220V
Packaging Type
Carton Box
Phase
Single Phase
Country of Origin
India
Applicability
Generally Applicable To All Geosynthetics
Specimen Clamping
Between Two Steel Rings
Cone Specifications
45° Tip Angle, 1000 G
Drop Height
500 Mm
Penetration Measurement
Graduated Cone Insertion
Usage
Geosynthetics Penetration Resistance Testing
Test Principle
Simulation Of Dropping Sharp Stones On Geosynthetics Surface
Brand Name
Milestone
Warranty
1 Year
Product Code
ME.GE-1002
Method to determine the resistance of geosynthetics to penetration by steel cone dropped from a fixed height, as a simulation of dropping sharp stones on their surface. Generally applicable to all geosynthetics. However, the test principle may not be applicable to some types of products. The specimen is clamped between two steel rings. A steel cone (45° tip angle, 1000 g) is dropped from a height of 500 mm onto the centre of the specimen. The degree of penetration is measured by insertion of a graduated cone into the hole.
